FAZ-C30/2-NA-DC - Eaton 30A 125Vdc 2-Pole C Curve Industrial Miniature Circuit Breaker

FAZ-C30/2-NA-DC

FAZ-C30/2-NA-DC is an Eaton industrial miniature circuit breaker designed for medium inrush current applications with a 30 amp rating and 125 Vdc voltage per pole.

This two-pole FAZ Series branch protector features a C curve trip characteristic suitable for small transformers and pilot devices. It has a 10 kA interrupting rating, screw terminals, and complies with UL 489 and CSA C22.2 No. 235 standards. The breaker mounts on a 35mm DIN rail and provides reliable thermal magnetic protection with a trip range of 5-10 times the nominal current.

Key Specifications
• Amperage: 30 A
• Voltage Rating: 125 Vdc per pole
• Poles: 2
• Trip Curve: C curve (medium inrush)
• Interrupt Rating: 10 kAIC
• Mounting Type: 35mm DIN rail
• Terminal Type: Screw terminals
• Standards: UL 489, CSA C22.2 No. 235
• Frequency: 50-60 Hz
• Trip Type: Thermal magnetic, 5-10X nominal current
• Weight: Approximately 1 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAZ-C30/2-NA-DC
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAZ Series
• Type : FAZ Series
• Voltage : 125
• Amperage : 30
• Phase : 1
• Poles : 2
• AIC rating : 10kA@125V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 4015081184774
• GTIN : 04015081184774
• Country of Origin : Spain
• Dimensions : 1.4 in x 4.13 in x 2.97 in (Length/Depth x Height x Width)
• Weight : 1
• Certification : CSA Std. C22.2 No. 235, UL 489
