FAP34100TF - Square D FAP Series 100A 3P 480V Molded Case Circuit Breaker with Thermal Magnetic Trip

FAP34100TF

FAP34100TF is a Square D FAP Series molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems. This breaker features a 100A current rating, 3-pole configuration, and is rated for 480V systems. It utilizes a thermal magnetic trip unit for both overload and short-circuit protection, ensuring safe and efficient operation. The FAP34100TF is built for feed-thru mounting and is suitable for use in a variety of panelboard and switchgear applications. The FAP34100TF is part of Square D's FAP series, known for durability and performance in demanding environments. It is equipped with a thermal magnetic trip unit, providing both long-time and instantaneous protection. The breaker is designed for use in systems up to 480V and offers an interrupting rating of 18kA at 480V. It is constructed with a molded case for added safety and reliability.

• 100A current rating
• 3-pole configuration
• 480V maximum voltage
• Thermal magnetic trip unit
• Feed-thru mounting
• FAP series frame
• 18kA interrupting rating at 480V
• UL listed
• CSA certified
• IEC rated
• Permanent trip design
• Line and load side lug terminals

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAP34100TF
• Manufacturer : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAP Series
• Type : FAP
• Voltage : 480
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• Weight : 5
