FAP34100 - Square D 100 Amp 3 Pole 480VAC I-Line Molded Case Circuit Breaker

FAP34100

FAP34100 is a Square D 100 Amp, 3 Pole molded case circuit breaker designed for I-Line panel mounting with thermal magnetic protection.This circuit breaker features a 480VAC voltage rating, 18kA interrupting capacity at 480V, and includes long-time and instantaneous trip functions. It has a plug-in I-Line style connection and load side lug terminals, suitable for 3-phase applications. The breaker meets UL and CSA certifications and is HACR rated for HVAC equipment.

• Manufacturer: Square D
• Series/Frame: FA
• Amperage: 100 Amp
• Voltage: 480VAC
• Poles: 3
• Mounting Type: I-Line Plug-In
• Interrupt Rating: 18kA at 480V
• Trip Unit: Thermal Magnetic with Long-Time and Instantaneous Trip
• Terminal Connection: Load Side Lug
• Certifications: UL, CSA, HACR
• Dimensions: 4.5" W x 4.13" D x 6.4" H
• Temperature Rating: 40°C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAP34100
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAP Series
• Type : FAP
• Voltage : 480
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 785901788465
• GTIN : 00785901858652
• Country of Origin : Mexico
• Dimensions : 6.4 in (162.6 mm) x 4.5 in (114.3 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 5
