FA360801021 - Square D 80 Amp 600 Volt 3 Pole I-Line Molded Case Circuit Breaker

FA360801021

FA360801021 is a Square D 3 pole molded case circuit breaker rated for 80 amps and 600 volts designed for I-Line mounting.

This thermal magnetic circuit breaker features a frame type F and is suitable for industrial power distribution applications requiring reliable overcurrent protection. It has a trip setting range from 800 to 1450 amps and interrupt ratings up to 25kA at 240VAC, 18kA at 480VAC, and 14kA at 600VAC, ensuring robust fault current interruption capability. The breaker is designed for plug-in I-Line mounting, facilitating easy installation and replacement in compatible switchgear.

Key Specifications
• Amperage: 80 Amps
• Voltage Rating: 600 Volts AC
• Number of Poles: 3
• Mounting Type: I-Line Plug-In
• Frame Type: F
• Interrupt Rating: 25kA @ 240VAC, 18kA @ 480VAC, 14kA @ 600VAC
• Trip Unit: Thermal Magnetic
• Trip Setting Range: 800 to 1450 Amps

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 120/240Vac shunt trip

Specifications

• Part Number: FA360801021
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : FA
• Voltage : 600
• Amperage : 80
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• GTIN : 00785901710332
• Country of Origin : Mexico
• Dimensions : 6.4 in (162.6 mm) x 4.5 in (114.3 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 9
