FA36080 - Square D 80A 600V 3-Pole I-Line Molded Case Circuit Breaker

FA36080

FA36080 is a Square D 80 Amp, 600 Volt, 3-Pole I-Line molded case circuit breaker designed for reliable circuit protection.FA36080 features a thermal magnetic trip unit and is rated for 80% continuous current. It has a plug-on mounting type compatible with I-Line panelboards and offers a high interrupting rating of up to 14kA at 600V. This breaker is part of the FA series with an F frame and is UL listed for safety and performance.

• Amperage: 80A
• Voltage: 600V
• Poles: 3
• Mounting Type: I-Line Plug-On
• Interrupt Rating: 14kA @ 600V
• Series/Frame: FA Series, F Frame
• Trip Unit: Thermal Magnetic
• Certifications: UL Listed
• Breaking Capacity Code: A
• Magnetic Hold Current: 800A
• Magnetic Trip Current: 1450A

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FA36080
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : FA
• Voltage : 600
• Amperage : 80
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901338758
• GTIN : 00785901338758
• Country of Origin : Mexico
• Dimensions : 6.4 in (162.6 mm) x 4.5 in (114.3 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 9
