EHD3090L - Cutler Hammer 90 Amp 480V 3-Pole Molded Case Circuit Breaker, EHD Series, Thermal-Magnetic Trip, 14kA Interrupt

EHD3090L

EHD3090L is a Cutler Hammer molded case circuit breaker designed for reliable protection in commercial and industrial power distribution applications.

This 3-pole, 90 amp breaker features a thermal-magnetic trip unit, 480V AC voltage rating, and a robust EHD series frame. It is engineered for fixed mounting, offers a 14kA interrupting rating at 480V AC, and is suitable for use in a wide range of electrical systems. The non-interchangeable trip unit ensures consistent performance and safety.

Key Specifications
• Amperage: 90A
• Voltage: 480V AC
• Poles: 3
• Mounting Type: Fixed
• Interrupt Rating: 14kA @ 480V AC
• Series/Frame: EHD
• Trip Unit: Thermal-magnetic, non-interchangeable
• Certifications: Not specified in available data
• Terminal Connection: Screw
• Wire Size: 14-1/0 AWG
• Trip Type: T186
• Application: Commercial and industrial power distribution

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD3090L
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 90
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679399729
• GTIN : 00786679399729
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
