EHD3090BP10 - Westinghouse 90A 480V 3 Pole Bolt-On Circuit Breaker Series C

EHD3090BP10

EHD3090BP10 is a Westinghouse Series C molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems. This 3 pole, 90 amp, 480 volt bolt-on circuit breaker features a robust construction for secure mounting and dependable operation in demanding environments. The breaker is part of the Series C family, known for its compatibility and performance in a wide range of applications. This circuit breaker is engineered for easy installation and maintenance, with a bolt-on mounting style that ensures a stable connection. It is suitable for use in panelboards and switchgear where space and reliability are critical. The breaker is designed to meet the requirements of modern electrical systems, providing effective overcurrent protection.

• Part Number: EHD3090BP10
• Manufacturer: Westinghouse
• Series: Series C
• Amperage Rating: 90 A
• Voltage Rating: 480 V
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 30,000 AIC (asymmetrical)
• Trip Unit: Thermal Magnetic
• Frame Type: Complete Breaker
• Standards: UL 489 Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD3090BP10
• Manufacturer : Westinghouse
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 90
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786685020655
• GTIN : 00786685020655
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
