Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EHD3090LBP10
EHD3090LBP10 is a 3-pole molded case circuit breaker from Eaton's Series C, designed for reliable circuit protection in industrial and commercial applications.This Eaton circuit breaker features a fixed thermal, fixed magnetic trip unit, rated for 90 amps and 480 volts AC. It is an F-frame breaker with line and load terminals, suitable for 50/60 Hz systems. The breaker has an interrupt rating of 18 kAIC at 240 VAC and 14 kAIC at 480 VAC, ensuring robust short-circuit protection. It is a complete breaker type designed for load-side mounting.
- Amperage Rating: 90 A
- Voltage Rating: 480 VAC
- Number of Poles: 3
- Frame Size: F-frame
- Series: Series C
- Trip Type: Fixed thermal, fixed magnetic
- Interrupt Rating: 18 kAIC at 240 VAC, 14 kAIC at 480 VAC
- Frequency Rating: 50/60 Hz
- Terminals: Line and load
- Circuit Breaker Type: Complete breaker
Specifications
- Part Number: EHD3090LBP10
- Manufacturer : Eaton
- Brand : Culter Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EHD
- Voltage : 480
- Amperage : 90
- Phase : 3
- Poles : 3
- AIC rating : 14kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 4
