Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EHD3070Y
EHD3070Y is an Eaton Series C complete molded case circuit breaker designed for industrial and commercial power distribution applications. This three-pole breaker features fixed thermal and fixed magnetic trip protection with an F-frame configuration and toggle actuator for reliable overcurrent and short-circuit protection. EHD3070Y delivers 70 amperes at 480 volts AC with an interrupt rating of 14 kAIC at 480 Vac and 18 kAIC at 240 Vac, making it suitable for demanding electrical systems. The breaker includes line and load side lug terminals for flexible installation and operates at 50/60 Hz frequency.
- Amperage Rating: 70A
- Voltage Rating: 480V AC
- Number of Poles: Three-pole
- Circuit Breaker Type: EHD
- Frame Type: F-Frame
- Trip Type: Fixed Thermal/Fixed Magnetic (T186)
- Interrupt Rating: 14 kAIC at 480 Vac, 18 kAIC at 240 Vac
- Terminals: Line and Load
- Frequency Rating: 50/60 Hz
- Mounting Style: Free Standing
- Certifications: UL Listed
- Warranty: One year from installation or eighteen months from shipment, whichever occurs first
Specifications
- Part Number: EHD3070Y
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EHD
- Voltage : 480
- Amperage : 70
- Phase : 3
- Poles : 3
- AIC rating : 14kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 4
