EHD3070L - Cutler Hammer 70 Amp 480V 3 Pole Series C Molded Case Circuit Breaker F-Frame

EHD3070L

EHD3070L is a Cutler Hammer Series C molded case circuit breaker designed for reliable protection in electrical systems.This 3 pole breaker features a 70 amp rating with a maximum voltage of 480 VAC and 250 VDC. It has an F-frame design and a thermal-magnetic trip unit for dependable circuit interruption. The breaker offers an interrupt rating of 14 kA at 480 VAC and 18 kA at 240 VAC, suitable for industrial and commercial applications. It includes screw terminal connections and is rated for operation at 40 degrees Celsius.

Key Specifications
• Amperage: 70 Amp
• Voltage: 480 VAC / 250 VDC
• Poles: 3
• Frame: F-Frame
• Series: Series C
• Interrupt Rating: 14 kA at 480 VAC, 18 kA at 240 VAC
• Trip Unit: Thermal-Magnetic
• Terminal Type: Screw
• Frequency: 50/60 Hz
• Mounting Type: Molded Case
• Operating Temperature: 40°C
• Certifications: UL Listed
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: EHD3070L
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 70
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic



Product Data

• UPC : 786679317181
• GTIN : 00786679317181
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
