EHD3070 - Westinghouse 70 Amp 480V 3-Pole Molded Case Circuit Breaker, F-Frame, Bolt-On, 14kAIC, Thermal Magnetic Trip, UL Listed

EHD3070

EHD3070 is a Westinghouse (Eaton/Cutler-Hammer) Series C, F-Frame, 3-pole molded case circuit breaker designed for reliable power distribution.

This circuit breaker features a 70 Amp rating, 480V AC/250V DC voltage, bolt-on mounting, and a 14 kA interrupting capacity at 480V. It is equipped with a fixed thermal magnetic trip unit (LI - Long-Time and Instantaneous), non-interchangeable trip, and line & load side lug terminals. The EHD3070 is UL Listed and operates at 50/60 Hz, making it suitable for a wide range of commercial and industrial applications.

Key Specifications

• Part Number: EHD3070
• Manufacturer: Westinghouse (Eaton/Cutler-Hammer)
• Amperage: 70A
• Voltage: 480V AC / 250V DC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 14 kAIC @ 480V
• Series/Frame: Series C, F-Frame, Type EHD
• Trip Unit: Fixed Thermal Magnetic (LI)
• Certifications: UL Listed
• Frequency: 50/60 Hz
• Connection: Feed-Thru
• Dimensions: 6" x 4.13" x 3.38"

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD3070
• Manufacturer : Westinghouse
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 70
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Load Side Lug
• Frame Size : 100A/F
• Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 786679317174
• GTIN : 00786679317174
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
