EHD3045 - Eaton 45 Amp 3 Pole 480 Volt Molded Case Circuit Breaker, Series C EHD Frame

EHD3045

EHD3045 is a 45 Amp, 3 Pole, 480 Volt molded case circuit breaker from Eaton's Series C EHD frame designed for panel mounting.This Eaton EHD3045 circuit breaker features thermal magnetic protection with long-time and instantaneous trip functions. It has a bolt-on connection type, a 14kA interrupt rating at 480V and 18kA at 240V, and is UL and CSA certified. The breaker is suitable for three-phase applications and includes line and load side lug terminals.

Key Specifications
• Amperage: 45 Amp
• Voltage: 480 Volt
• Poles: 3
• Mounting Type: Panel Mount
• Interrupt Rating: 14 kA at 480 VAC, 18 kA at 240 VAC
• Frame Type: EHD (Series C)
• Trip Unit: Thermal Magnetic with Long-Time and Instantaneous
• Connection Type: Bolt-On
• Phase: 3
• Certifications: UL, CSA
• Dimensions (HxWxD): 6 x 4.13 x 3.38 inches

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD3045
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 45
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679317587
• GTIN : 00786679317587
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.3
• Certification : UL Listed
