Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EHD3030L
EHD3030L is a 30 Amp, 3-pole, 480 Volt Eaton Series C complete molded case circuit breaker designed for reliable industrial and commercial circuit protection.This Eaton EHD3030L circuit breaker features a thermal magnetic trip unit with fixed thermal and magnetic trip settings, providing dependable overcurrent protection. It is an F-frame breaker with a feed-thru mounting type, rated for 14kA interrupt capacity at 480 VAC and 18kA at 240 VAC. The breaker includes line and load side lug terminals and is UL listed for panelboard, switchboard, motor control center, and busway applications.
- Key Specifications
- Amperage: 30 Amps
- Voltage: 480 VAC
- Poles: 3
- Frame Type: F-Frame
- Mounting Type: Feed-Thru
- Interrupt Rating: 14kA at 480 VAC, 18kA at 240 VAC
- Trip Unit: Thermal Magnetic, Fixed
- Series: Eaton Series C
- Connection: Line & Load Side Lug Terminals
- Certifications: UL Listed
- Dimensions: 6" H x 4.13" W x 3.38" D
- Weight: 4.55 lbs
- Part Number: EHD3030L
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EHD
- Voltage : 480
- Amperage : 30
- Phase : 3
- Poles : 3
- AIC rating : 14kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
- UPC : 786679317105
- GTIN : 00786679317105
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
