EHD3020L - Westinghouse Eaton 20 Amp 3 Pole 480 Volt Molded Case Circuit Breaker F Frame Series C

EHD3020L

EHD3020L is a Westinghouse Eaton molded case circuit breaker designed for reliable circuit protection.This 3 pole, 20 amp breaker operates at 480 volts with a thermal magnetic trip unit and a non-interchangeable LI (Long-Time and Instantaneous) trip function. It features a feed-thru connection type, F frame size, and a 14kA interrupt rating at 480V. The breaker is part of Eaton's Series C and is suitable for three-phase applications.

Key Specifications
• Manufacturer: Westinghouse Eaton
• Part Number: EHD3020L
• Amperage: 20 Amp
• Voltage: 480 Volt
• Poles: 3
• Frame Type: F Frame
• Series: Series C
• Trip Unit: Thermal Magnetic, LI (Long-Time and Instantaneous)
• Interrupt Rating: 14kA at 480V
• Connection Type: Feed-Thru
• Phase: 3
• Dimensions: 6" x 4.13" x 3.38"
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: EHD3020L
• Manufacturer : Westinghouse
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 20
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic



Product Data

• UPC : 786679317075
• GTIN : 00786679317075
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
