EHD1090L - Eaton 90A 1-Pole 277VAC Molded Case Circuit Breaker F-Frame Series C

EHD1090L

EHD1090L is a 90 amp, single-pole molded case circuit breaker from Eaton's Series C F-frame lineup designed for reliable circuit protection at 277 volts AC.

This Eaton EHD1090L breaker features a fixed thermal and fixed magnetic trip unit, load-side terminals, and a bolt-on mounting type. It is UL Listed and rated for 18 kA interrupt capacity at 240 VAC and 14 kA at 480 VAC, suitable for 50/60 Hz applications. The breaker measures 6 inches in height, 3.38 inches in depth, and 1.38 inches in width, weighing approximately 2 pounds.

• Amperage: 90 A
• Voltage Rating: 277 VAC
• Number of Poles: 1 (Single-Pole)
• Frame Type: F-Frame
• Series: Series C
• Trip Type: Fixed Thermal, Fixed Magnetic
• Interrupt Rating: 18 kAIC at 240 VAC, 14 kAIC at 480 VAC
• Frequency: 50/60 Hz
• Mounting Type: Bolt-On
• Terminals: Load Side
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD1090L
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 277
• Amperage : 90
• Phase : 1
• Poles : 1
• AIC rating : 14kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679050620
• GTIN : 00786679050620
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
• Weight : 2
• Certification : UL Listed
