EHD1090 - Cutler Hammer Eaton Westinghouse 90A 277V 1 Pole Circuit Breaker Series C EHD Frame

EHD1090

EHD1090 is a Cutler Hammer, Eaton, and Westinghouse molded case circuit breaker designed for reliable circuit protection.This 90 amp, 1 pole circuit breaker operates at 277 volts AC and belongs to the Series C family with an EHD frame. It features a bolt-on mounting type and a 14kA interrupting rating at 480 volts, suitable for industrial and commercial applications. The breaker is rated for standard interrupting capacity and designed for 40 degree C ambient temperature operation.

• Manufacturer: Cutler Hammer / Eaton / Westinghouse
• Amperage: 90A
• Voltage: 277V AC
• Poles: 1 (Single Pole)
• Series/Frame: Series C, EHD Frame
• Mounting Type: Bolt-On
• Interrupt Rating: 14kA @ 480V
• Trip Unit: Thermal Magnetic
• Temperature Rating: 40°C
• Certifications: UL Listed, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD1090
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 277
• Amperage : 90
• Phase : 1
• Poles : 1
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679317556
• GTIN : 00786679317556
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
• Weight : 2
• Certification : UL Listed
