EHD1080 - Cutler Hammer 80A 277V 1 Pole Molded Case Circuit Breaker Bolt-On Frame EHD

EHD1080

EHD1080 is an 80 amp, 277 volt, single-pole molded case circuit breaker from Cutler Hammer designed for reliable circuit protection.EHD1080 features a bolt-on mounting type with a thermal magnetic trip unit providing long time and instantaneous trip functions. It has a 14kA interrupt rating at 480V and is part of the EHD series/frame. This breaker is suitable for single-phase applications and includes load side lug terminals. It is UL listed and designed for use in commercial and industrial electrical systems.

Key Specifications
• Amperage: 80A
• Voltage: 277 VAC
• Poles: 1
• Mounting Type: Bolt-On
• Interrupt Rating: 14kA @ 480V
• Series/Frame: EHD
• Trip Unit: Thermal Magnetic (Long Time and Instantaneous)
• Phase: Single Phase
• Load Side Lug Terminals
• Non-Interchangeable Trip
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD1080
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 277
• Amperage : 80
• Phase : 1
• Poles : 1
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679317549
• GTIN : 00786679317549
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
• Weight : 2
• Certification : UL Listed
