EHD1030L - Eaton 30 Amp 277/480V 1-Pole Molded Case Circuit Breaker, F-Frame, Series C, Thermal Magnetic Trip, UL Listed

EHD1030L

EHD1030L is a single-pole, 30 Amp molded case circuit breaker from Eaton, designed for reliable protection in commercial and industrial applications.

This Eaton Series C, F-Frame breaker features a thermal magnetic trip unit (T186) for both long-time and instantaneous overcurrent protection, with a maximum voltage rating of 480V AC and an interrupting rating of 14kA at 480V. It is UL Listed for safety and compliance, and is suitable for 50/60 Hz systems. The feed-thru connection and lug terminations on both line and load sides ensure easy installation and maintenance.

Key Specifications

• Part Number: EHD1030L
• Manufacturer: Eaton
• Amperage: 30A
• Voltage: 277V/480V AC
• Poles: 1
• Mounting Type: Fixed
• Interrupt Rating: 14kA @ 480V AC
• Series/Frame: Series C, F-Frame
• Trip Unit: Thermal Magnetic (T186), LI (Long-Time & Instantaneous)
• Connection: Feed-Thru, Lug Terminals
• Frequency: 50/60 Hz
• Certifications: UL Listed
• Protection: Thermal Magnetic

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD1030L
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 277
• Amperage : 30
• Phase : 1
• Poles : 1
• AIC rating : 14kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679156803
• GTIN : 00786679156803
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
• Weight : 2
• Certification : UL Listed
