EDS2100 - Eaton 100A 240V 2-Pole Series C Molded Case Circuit Breaker F-Frame Bolt-On

EDS2100

EDS2100 is a 2-pole, 100 amp, 240 volt molded case circuit breaker from Eaton's Series C, F-frame family designed for bolt-on mounting.This Eaton EDS2100 circuit breaker features a thermal magnetic trip unit with fixed thermal and magnetic protection. It has a 42kA interrupt rating at 240 VAC and supports both 240 VAC and 125 VDC voltage ratings. The breaker is designed for load-side lug connections and busbar line-side terminations. It complies with industry standards for safety and reliability.

• Amperage: 100A
• Voltage: 240 VAC, 125 VDC
• Poles: 2
• Mounting Type: Bolt-On
• Interrupt Rating: 42kA at 240 VAC
• Series/Frame: Series C, F-Frame
• Trip Unit: Thermal Magnetic (Fixed Thermal, Fixed Magnetic)
• Connection: Load side lugs, line side busbar
• Phase: 2
• Category: Molded Case Circuit Breaker
• Dimensions (HxWxD): 3.38 x 6 x 4.13 inches
• Weight: Approximately 3 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDS2100
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EDS
• Voltage : 240
• Amperage : 100
• Phase : 2
• Poles : 2
• AIC rating : 42kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 782116152698
• GTIN : 00782116152698
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
