2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
EDS2125
EDS2125 is a Cutler Hammer 2-pole molded case circuit breaker rated for 125 amps and 240 volts, part of the Series C family.EDS2125 features a thermal magnetic trip unit with a 42kA interrupt rating at 240V, bolt-on mounting, and an F frame size. It is UL listed and designed for reliable protection in panel applications.
- Key Specifications
- Amperage: 125A
- Voltage: 240V AC
- Poles: 2
- Interrupt Rating: 42kA @ 240V
- Trip Unit: Fixed Thermal / Fixed Magnetic
- Mounting Type: Bolt-On
- Series/Frame: Series C, F Frame
- Certifications: UL Listed
- Connection: Load Side Lug Terminals
- Country of Origin: Dominican Republic
- Dimensions: 3.38in L x 2.75in H x 2.75in W
- Weight: 3.5 lbs
Specifications
- Part Number: EDS2125
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EDS
- Voltage : 240
- Amperage : 125
- Phase : 2
- Poles : 2
- AIC rating : 42kA@240V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 782116152674
- GTIN : 00782116152674
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
- Weight : 3
- Certification : UL Listed
