Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EDB3200L
EDB3200L is a 200 Amp, 3-pole molded case circuit breaker from Eaton's Series C, F frame family designed for 240 Volt applications.
This Eaton EDB3200L breaker features a fixed thermal magnetic trip unit, providing reliable protection with a 22 kA interrupt rating at 240 VAC. It supports both line and load side lugs and operates at 50/60 Hz frequency. The breaker is UL listed and designed for heavy-duty industrial and commercial electrical distribution systems.
- Amperage: 200 Amp
- Voltage Rating: 240 VAC, 125 VDC
- Poles: Three Pole
- Frame Type: F Frame
- Series: Series C
- Trip Unit: Fixed Thermal Magnetic
- Interrupt Rating: 22 kA at 240 VAC
- Mounting Type: Molded Case
- UL Listed
- Frequency: 50/60 Hz
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: EDB3200L
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EDB
- Voltage : 240
- Amperage : 200
- Phase : 3
- Poles : 3
- AIC rating : 22kA@240V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Terminal Connection : Lug
- Frame Size : F Frame
- Temp Rating : 104 ¡F (40 ¡C)
- Protection : Thermal Magnetic
Product Data
- UPC : 782116976171
- GTIN : 00782116976171
- Country of Origin : Mexico
- Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 3
- Standards : cULus, IEC
- Certification : cULus, IEC
