EDB14050SA - Schneider Electric (Square D) 1-Pole 50 A 480Y/277 V AC Bolt-On Circuit Breaker with Shunt Trip, Type EDB

EDB14050SA

EDB14050SA is a Schneider Electric E-Frame miniature circuit breaker rated at 50A, 1 pole, 277 VAC with bolt-on mounting and factory-installed shunt trip.This thermal-magnetic miniature circuit breaker provides superior overload and short-circuit protection for lighting panelboards. It features Visi-Trip indicator for faster troubleshooting, HID and HACR ratings, and supports AWG 14-2/0 copper or AWG 12-2/0 aluminum conductors. The EDB series breaker occupies 2 spaces in NF panelboards with 18 kA interrupting capacity at 277 VAC and 25 kA max at 120 VAC.

• Amperage Rating: 50 A
• Number of Poles: 1
• Voltage Rating: 277 VAC
• Frame Size: E-Frame (125 A Frame EDB-EGB-EJB)
• Mounting Type: Bolt-on
• Trip Unit: Thermal-magnetic
• Shunt Trip: Yes
• Interrupt Rating: 18 kA @ 277 VAC, 25 kA @ 120 VAC
• Breaking Capacity Code: D
• Product Certifications: cULus, IEC
• Dimensions: 5.66 in H x 1.96 in W x 4.05 in D
• Net Weight: 2 lb (0.91 kg)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 120V shunt trip

Specifications

• Part Number: EDB14050SA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EDB Series
• Type : EDB
• Voltage : 277
• Amperage : 50
• Phase : 1
• Poles : 1
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Temp Rating : 104 ¡F (40 ¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901932772
• GTIN : 00785901932772
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 1.96 in (49.78 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 2.05
• Standards : cULus, IEC
• Certification : cULus, IEC
