EDB14035SA - Schneider Electric (Square D) 1-Pole 35 A 480Y/277 V AC Bolt-On Circuit Breaker with Shunt Trip, Type EDB

SKU: EDB14035SA-ReCert
Condition: Re-Certified
Price:
$337.04
Stock:
Low inventory, please call for stock check
This ships in 1-2 business days

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

EDB14035SA - Schneider Electric/ Square D Bolt-On 35 Amp 1 Pole Circuit Breaker - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
EDB14035SA - Schneider Electric/ Square D Bolt-On 35 Amp 1 Pole Circuit Breaker - Essential Electric Supply

Description

EDB14035SA


EDB14035SA - Schneider Electric mini circuit breaker with shunt trip, E-Frame, rated 35A, 1 pole, 277VAC, bolt-on mounting.This EDB14035SA is a thermal-magnetic molded case circuit breaker from the EDB series, providing superior overload and short circuit protection with Visi-Trip technology for faster troubleshooting. It features a shunt trip for remote operation and is designed for use in lighting panelboards.
  • Part Number: EDB14035SA
  • Manufacturer: Schneider Electric
  • Type: Mini circuit breaker, E-Frame
  • Amperage: 35A
  • Poles: 1 pole
  • Voltage: 277VAC
  • Mounting: Bolt-on
  • Interrupt Rating: 25kA max
  • Trip Unit: Thermal-magnetic with shunt trip
  • Wire Range: AWG 14-2/0 copper, AWG 12-2/0 aluminum
  • Ratings: HID rated, HACR rated
  • Certifications: UL listed, CSA, HOM certified
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 120V shunt trip


Specifications

  • Part Number: EDB14035SA
  • Manufacturer : Schneider Electric
  • Brand : Square D
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : EDB Series
  • Type : EDB
  • Voltage : 277
  • Amperage : 35
  • Phase : 1
  • Poles : 1
  • AIC rating : 18kA@480V
  • Connection : Bolt-On
  • Functions : LI - Long-Time and Instantaneous
  • Terminal Connection : Lug
  • Temp Rating : 104 ¡F (40 ¡C)
  • Protection : Thermal Magnetic

Product Data

  • Country of Origin : Mexico
  • Dimensions : Width 14.25 in (362 mm) Height 39.37 in (1000 mm)
  • Weight : 2
  • Standards : cULus, IEC
  • Certification : cULus, IEC
