EDB14030EPD - Square D 30A 277V 1 Pole Bolt-On Circuit Breaker EDB Series

Save $677.46
SKU: EDB14030EPD-New
Condition: New
Price:
$473.54 $1,151.00
Stock:
63 In stock, ready to be shipped

Same-Day Shipping

Most items ship same-day if ordered by 1:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

EDB14030EPD - Square D/ Schneider Electric Bolt-On 30 Amp 1 Pole Circuit Breaker - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
EDB14030EPD - Square D/ Schneider Electric Bolt-On 30 Amp 1 Pole Circuit Breaker - Essential Electric Supply

Description

EDB14030EPD


EDB14030EPD is a Square D molded case circuit breaker designed for lighting panelboard applications, offering reliable overload and short circuit protection in a compact bolt-on configuration. This single-pole, thermal-magnetic breaker delivers superior protection for 277VAC systems with a 30-amp current rating calibrated for 40 degrees Celsius operation. The breaker features long-time and instantaneous trip functions with a 25kA maximum interrupt rating at 120VAC and includes 30mA ground fault protection for enhanced safety.
  • Amperage: 30A
  • Voltage: 277VAC
  • Poles: 1
  • Phase: 1
  • Series: EDB (E-Frame)
  • Mounting Type: Bolt-On
  • Trip Unit: Thermal-Magnetic with LI (Long-Time and Instantaneous)
  • Interrupt Rating: 25kA @ 120VAC
  • Ground Fault Protection: 30mA
  • Certifications: UL Listed, CSA Certified, HACR Rated, NOM 117 Certified
  • Wire Compatibility: 14 to 6 AWG (aluminum/copper)
  • Dimensions: 4.05 x 1.96 x 6.64 inches
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: EDB14030EPD
  • Manufacturer : Schneider Electric
  • Brand : Square D
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : EDB Series
  • Type : EDB
  • Voltage : 277
  • Amperage : 30
  • Phase : 1
  • Poles : 1
  • AIC rating : 18kA@480V
  • Connection : Bolt-On
  • Functions : LI - Long-Time and Instantaneous
  • Terminal Connection : Lug
  • Frame Size : 125A/EDB
  • Temp Rating : 104 ¡F (40 ¡C)
  • MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 4 AWG (Al), 6 AWG (Cu)
  • Breaker Type : Ground Fault Equipment Protection
  • Protection : Thermal Magnetic

Product Data

  • UPC : 785901475576
  • GTIN : 00785901475576
  • Country of Origin : Mexico
  • Dimensions : 6.64 in (168.66 mm) x 1.96 in (49.78 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
  • Weight : 2.1
  • Panel Type : NF panelboard
  • Standards : cULus, IEC
  • Certification : cULus, IEC
  • Wire Size : AWG 14...AWG 6 copper
    AWG 12...AWG 4 aluminum

Accesories

Part Manufacture Sub Category
ECB2HT
