EDB14015SA - Schneider Electric (Square D) 1-Pole 15 A 480Y/277 V AC Bolt-On Circuit Breaker with Shunt Trip, Type EDB

Save $725.86
SKU: EDB14015SA-ReCert
Condition: Re-Certified
Price:
$179.14 $905.00
Stock:
Low inventory, please call for stock check
This ships in 1-2 business days

Same-Day Shipping

Most items ship same-day if ordered by 1:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

EDB14015SA - Schneider Electric/ Square D Bolt-On 15 Amp 1 Pole Circuit Breaker - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
EDB14015SA - Schneider Electric/ Square D Bolt-On 15 Amp 1 Pole Circuit Breaker - Essential Electric Supply

Description

EDB14015SA


EDB14015SA is a Schneider Electric E-Frame mini circuit breaker rated at 15A, 1 pole, 277VAC with bolt-on mounting and shunt trip.This molded case circuit breaker from the EDB series provides superior overload and short circuit protection for lighting panelboards. It features thermal-magnetic trip unit, Visi-Trip indicator for faster troubleshooting, and is Switching Duty, HID, and HACR rated with aluminum lugs.
  • Part Number: EDB14015SA
  • Manufacturer: Schneider Electric
  • Series/Frame: E-Frame / EDB
  • Amperage: 15A
  • Poles: 1
  • Voltage: 277VAC
  • Mounting Type: Bolt-On
  • Trip Unit: Thermal-Magnetic (LI)
  • Interrupt Rating: 25kA@120VAC, 18kA@277VAC
  • Shunt Trip: Yes
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 120V shunt trip


Specifications

  • Part Number: EDB14015SA
  • Manufacturer : Schneider Electric
  • Brand : Square D
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : EDB Series
  • Type : EDB
  • Voltage : 277
  • Amperage : 15
  • Phase : 1
  • Poles : 1
  • AIC rating : 18kA@480V
  • Connection : Bolt-On
  • Functions : LI - Long-Time and Instantaneous
  • Terminal Connection : Lug
  • Temp Rating : 104 ¡F (40 ¡C)
  • Protection : Thermal Magnetic

Product Data

  • GTIN : 00785901691372
  • Country of Origin : Mexico
  • Dimensions : 5.66 in (143.76 mm) x 1.96 in (49.78 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
  • Weight : 2.061
  • Panel Type : NF panelboard
  • Standards : cULus, IEC
  • Certification : cULus, IEC
  • Wire Size : AWG 12...AWG 6 aluminum
    AWG 14...AWG 6 copper
