CSH2175N - Cutler Hammer 175A 240V 2 Pole Main Circuit Breaker 35kAIC CSR Frame

CSH2175N

CSH2175N is a 2-pole, 175A, 240V main circuit breaker designed for Eaton CH load centers with a 35kAIC interrupt rating and CSR frame. This Cutler Hammer CSH2175N main breaker features a plug-in mounting design, thermal-magnetic trip unit, and is suitable for residential and commercial applications requiring reliable overcurrent protection at 120/240VAC.

• Manufacturer: Cutler Hammer (Eaton)
• Part Number: CSH2175N
• Amperage: 175A
• Voltage: 120/240VAC
• Poles: 2
• Interrupt Rating: 35kAIC @ 240V
• Mounting Type: Plug-In
• Series/Frame: CSR
• Frame Size: CH
• Series Type: CSH
• Wire Size: 2 AWG to 300 kcmil Cu/Al
• Trip Unit: Thermal-Magnetic
• Certifications: UL, CSA

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CSH2175N
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Type CH
• Type : CSH
• Voltage : 240
• Amperage : 175
• Phase : 1
• Poles : 2
• AIC rating : 35kA@240V
• Connection : Plug-In
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 782113099750
• GTIN : 00782113099750
• Country of Origin : Dominican Republic
• Dimensions : 1 in x 1 in x 1 in (Length/Depth x Height x Width)
• Weight : 1
• Certification : UL Listed
• Wire Size : #2 AWG to 300KCmil CU/AL
