CSH2125N - Cutler Hammer 125A 2-Pole 120/240V Circuit Breaker 35kAIC Thermal Magnetic Bolt-On

CSH2125N

CSH2125N is a Cutler Hammer 125 amp, 2-pole main circuit breaker designed for 120/240 VAC applications with a 35 kA interrupt rating.CSH2125N features a thermal magnetic trip unit with fixed trip settings and bolt-on mounting, compatible with Eaton CH load centers and ECB unit enclosures. It supports wire sizes from #2 AWG to 300 kcmil copper or aluminum and is UL and CSA certified for residential use.

• Amperage: 125 A
• Voltage: 120/240 VAC
• Poles: 2
• Interrupt Rating: 35 kAIC
• Trip Unit: Thermal Magnetic, Fixed Trip
• Mounting Type: Bolt-On
• Frame/Series: CSH
• Wire Size Range: #2 AWG to 300 kcmil Cu/Al
• Certifications: UL Listed, CSA
• Compatible with Eaton CH Load Centers and ECB Enclosures
• Residential Application

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CSH2125N
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Type CH
• Type : CSH
• Voltage : 240
• Amperage : 125
• Phase : 1
• Poles : 2
• AIC rating : 35kA@240V
• Connection : Plug-In
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786685229126
• GTIN : 00786685229126
• Country of Origin : Dominican Republic
• Dimensions : 1 in x 1 in x 1 in (Length/Depth x Height x Width)
• Weight : 1
• Certification : UL Listed
• Wire Size : #2 AWG to 300KCmil CU/AL
