CSH2150N - Cutler Hammer 150A 120/240V 2-Pole CSH Frame Main Circuit Breaker 35kAIC

CSH2150N

CSH2150N is a Cutler Hammer main circuit breaker designed for reliable power distribution and protection.This 150 amp, 2-pole circuit breaker features a 120/240 volt rating and a 35 kA interrupt rating, suitable for use in Type ECB unit enclosures. It uses a thermal/magnetic trip unit and supports wire sizes from #2 AWG to 300 kcmil copper or aluminum conductors. The breaker is bolt-on mounted and UL listed for safety and performance.

• Amperage: 150 A
• Voltage Rating: 120/240 V
• Number of Poles: 2
• Interrupt Rating: 35 kAIC
• Frame Type: CSH
• Trip Unit: Thermal/Magnetic
• Mounting Type: Bolt-On
• Wire Size Range: #2 AWG to 300 kcmil Cu/Al
• Certifications: UL Listed
• Compatible with Type ECB Unit Enclosures

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CSH2150N
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Type CH
• Type : CSH
• Voltage : 240
• Amperage : 150
• Phase : 1
• Poles : 2
• AIC rating : 35kA@240V
• Connection : Plug-In
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 782113099743
• GTIN : 00782113099743
• Country of Origin : Dominican Republic
• Dimensions : 6.5 in x 5.25 in x 5.25 in (Length/Depth x Height x Width)
• Weight : 2.6
• Certification : UL Listed
• Wire Size : #2 AWG to 300KCmil CU/AL
