CN15NN3C - Eaton Freedom NEMA Size 4 Motor Contactor 135A 3-Pole 480V/440V Coil Voltage

CN15NN3C

CN15NN3C is an Eaton Freedom NEMA motor control contactor designed for full voltage non-reversing applications in an open NEMA Size 4 enclosure.This Eaton contactor features a 135 ampere rating with three poles and supports coil voltages of 480 V at 60 Hz or 440 V at 50 Hz. It is suitable for three-phase motor control and is rated for 40 hp at 208 V, 50 hp at 240 V, and 100 hp at 480/600 V. The contactor is part of Eaton's Freedom series and is designed for reliable motor control in industrial environments.

Key Specifications
• Amperage: 135 A
• Voltage: 480 V at 60 Hz / 440 V at 50 Hz coil voltage
• Poles: 3
• Mounting Type: Open NEMA Size 4 enclosure
• Series/Frame: Freedom Series, NEMA Size 4
• Type: Full voltage non-reversing contactor
• Phase: Three-phase
• Horsepower Ratings: 40 hp at 208 V, 50 hp at 240 V, 100 hp at 480/600 V
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: CN15NN3C
• Manufacturer : Eaton
• Brand : Eaton
• Category : Motor Control
• Item Subcategory : Contactor
• Voltage : 3
• Amperage : 135
• Phase : 3
• Poles : 3
• Horse Power : HP @ 3 Phase - 208V 40 hp HP @ 3 Phase - 240V 50 hp HP @ 3 Phase - 480V 100 hp
• Aux Contacts : 1NO
• Coil Voltage Maximum : 480
• Full Load Amps : 135 A
• Coil Voltage Minimum : 440



Product Data

• UPC : 782113622484
• GTIN : 00782113622484
• Country of Origin : United States
• Dimensions : 7.25 in x 9.11 in x 7.05 in (Length/Depth x Height x Width)
• Weight : 30
• Certification : CSA, UL Listed
