Product Description & Specifications
Confirm the complete catalog number and application requirements before ordering. The specifications below reflect the product information available for this listing.
- Manufacturer
- Eaton
- Sub-Category
- Contactor
- Series
- C25 Series
- Frame
- C
- Rated current
- 50
- Voltage
- 600V
- Poles
- 3
- Phases
- 3
- Coil voltage
- 120 V
- Coil Voltage Maximum
- 120
- UPC
- 782116311798
- GTIN
- 00782116311798
- Dimensions
- 3.35" X 3.75" X 2.4"
- Weight
- 1 lb
Product description & additional details
C25DNF350A
C25DNF350A is an Eaton definite purpose contactor designed for motor control applications with non-reversing operation and three-pole configuration.
This contactor features a 50-amp AC3 rating at 120VAC coil voltage with 110-120VAC operating range at 50/60 Hz. The unit comes in an open enclosure with metal mounting plate and quick connect terminals for side-by-side installation. It is rated for up to 3 HP at 115V single phase, 10 HP at 230V single phase, 15 HP at 230V three phase, and 30 HP at 460/575V three phase. The C25 series contactor is suitable for HVAC, refrigeration, and general motor control applications.
- Catalog Number: C25DNF350A
- Manufacturer: Eaton Corp
- Type: Definite Purpose Contactor, Non-Reversing
- Poles: 3 Pole
- Amperage: 50A AC3 Rated
- Coil Voltage: 120VAC
- Operating Voltage Range: 110-120VAC
- Frequency: 50/60 Hz
- Mounting: Open with Metal Mounting Plate
- Terminal Type: Quick Connect (Side-by-Side)
- Certifications: UL Listed (File E1491), CSA Certified, IEC
- Dimensions: 3.75 inches H x 8.38 inches W x 8.63 inches D
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: C25DNF350A
- Manufacturer : Eaton
- Brand : Eaton
- Category : Motor Control
- Item Subcategory : Contactor
- Family : C25 Series
- Type : C
- Voltage : 600
- Amperage : 50
- Phase : 3
- Poles : 3
- Coil Voltage Maximum : 120
Product Data
- UPC : 782116311798
- GTIN : 00782116311798
- Dimensions : 3.35" X 3.75" X 2.4"
- Weight : 1 lb
