2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
BQD380
BQD380 - Siemens 3-pole, 80 Amp molded case circuit breaker with thermal magnetic trip, rated for 480VAC.The Siemens BQD380 features a BQD frame, bolt-on mounting, and long time and instantaneous trip functions for reliable overcurrent protection in P1 panelboards. It offers lug terminals and an interrupting rating of 14kAIC at 480VAC.
- Part Number: BQD380
- Manufacturer: Siemens
- Amperage: 80A
- Voltage: 480VAC
- Poles: 3
- Frame/Series: BQD
- Mounting Type: Bolt-On
- Interrupt Rating: 14kAIC at 480VAC
- Trip Unit: Thermal Magnetic
- Certifications: UL, CSA
- Connection Type: Lug
- For Use With: P1 Panelboards
Specifications
- Part Number: BQD380
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : BQD Series
- Type : BQD
- Voltage : 480
- Amperage : 80
- Phase : 3
- Poles : 3
- AIC rating : 14kA@480V
- Connection : Bolt-on
- Functions : Long Time and Instantaneous Trip
- Terminal Connection : Lug
- Frame Size : 100A/BQD
- Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
- MCM Size : Min. Wire Size 6 AWG (Al), 8 AWG (Cu) Max. Wire Size 1/0 AWG
- Breaker Type : Standard
- Protection : Thermal Magnetic
Product Data
- UPC : 783643277441
- GTIN : 00783643277441
- Country of Origin : Mexico
- Dimensions : 3 in x 4.49 in x 4.49 in
- Weight : 1.649
- Panel Type : Siemens P1 Panelboards
- Standards : CSA-C22.2,UL 539
- Certification : CSA-C22.2,UL 539
