BQC220230 - Cutler Hammer Quadplex Circuit Breaker, 20A/30A, 120/240V, 4-Pole, Plug-On, 10kAIC, BR Series, Thermal Magnetic Trip, UL 489

BQC220230

BQC220230 is an Eaton quad molded case circuit breaker designed for residential applications with a common trip mechanism.

This thermal/magnetic circuit breaker features one 2-pole 20-amp branch and one 2-pole 30-amp branch, both operating at 120/240 VAC. The breaker uses a plug-in connection method on the line side with lug terminals on the load side. It includes a rejection tab feature for proper installation in compatible panels and conforms to the latest National Electrical Code standards.

• Voltage Rating: 120/240 VAC
• Amperage: (1) 20A 2-Pole and (1) 30A 2-Pole
• Interrupt Rating: 10 kA @ 120 VAC
• Number of Poles: 4 Poles (Quadplex)
• Trip Type: Thermal/Magnetic
• Mounting: Plug-In (Line Side)
• Load Side Termination: Lugs
• Frame Type: BQC
• Common Trip Mechanism: Yes
• Height: 3 inches
• Width: 2 inches
• Depth: 2.89 inches

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BQC220230
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BQ Series
• Type : BQC
• Voltage : 240
• Amperage : 30
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Bolt-on
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Lug
• Protection : Thermal Magnetic

Product Data

• UPC : 786676371858
• GTIN : 00786676371858
• Country of Origin : United States
• Dimensions : 2 in x 2.4 in x 3 in (Length/Depth x Height x Width)
• Weight : 0.75
• Standards : HACR Rated, UL Listed
• Certification : UL 489,Federal Specifications Classification W-C387
• Wire Size : AWG 14 to AWG 4, Cu/Al
