BE260H - Siemens 60A 2-Pole 120/240V Ground Fault Circuit Breaker, BLEH Frame, Bolt-On Mount, 22kA Interrupt, Thermal Magnetic Trip

BE260H

BE260H is a Siemens 2-pole ground fault circuit breaker designed for reliable protection in commercial and industrial applications.

This molded case circuit breaker features a thermal magnetic trip unit, bolt-on mounting, and a high interrupting capacity for enhanced safety and performance. It is part of the Siemens BL Series, BLEH frame, and is suitable for use in panels requiring robust ground fault protection.

Key Specifications
• Part Number: BE260H
• Manufacturer: Siemens
• Amperage: 60A
• Voltage: 120/240V AC
• Poles: 2
• Mounting Type: Bolt-On
• Interrupt Rating: 22kA @ 240V
• Series/Frame: BL Series, BLEH
• Trip Unit: Thermal Magnetic
• Ground Fault Protection: Yes (30mA)
• Actuator: Toggle
• Certifications: UL Listed (typical for Siemens molded case breakers; confirm with latest datasheet for specific model)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BE260H
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BL Series
• Type : BLEH
• Voltage : 240
• Amperage : 60
• Phase : 1
• Poles : 2
• AIC rating : 22kA@240V
• Connection : Bolt-On
• Functions : LI - Long Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : 60A/BLEH
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG
• Breaker Type : Ground Fault Equipment Protection
• Protection : Thermal Magnetic

Product Data

• UPC : 783643274211
• GTIN : 00783643274211
• Country of Origin : Philippines
• Dimensions : 1.969 x 2.756 x 5.906 inch
• Weight : 1.036
• Panel Type : Siemens P1 Panelboards
• Standards : CSA Certified, HACR Rated, NOM Certified, UL Listed
