BE250H - Siemens 50 Amp 2 Pole 120/240V Molded Case Circuit Breaker BLEH Frame

BE250H

BE250H is a Siemens 50 Amp 2 Pole molded case circuit breaker designed for reliable electrical protection in panel-mounted applications.This Siemens BE250H breaker features a BLEH/125A frame with a 22kA interrupt rating at 240VAC. It is a bolt-on type breaker with ground fault protection (GFCI 30mA) suitable for 120/240V systems. The breaker includes busbar line side connection and lug load side connection, ensuring secure and efficient installation.

• Amperage: 50 Amp
• Poles: 2
• Voltage: 120/240 VAC
• Interrupt Rating: 22kA at 240VAC
• Frame/Series: BLEH/125A
• Mounting Type: Bolt-On
• Ground Fault Protection: 30mA GFCI
• Line Side Termination: Busbar
• Load Side Termination: Lug (included)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BE250H
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BL Series
• Type : BLEH
• Voltage : 120/240
• Amperage : 50
• Phase : 1
• Poles : 2
• AIC rating : 22kA@240V
• Connection : Bolt-On
• Functions : LI - Long Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : 60A/BLEH
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG
• Breaker Type : Ground Fault Equipment Protection
• Protection : Thermal Magnetic

Product Data

• UPC : 783643274204
• GTIN : 00783643274204
• Country of Origin : Philippines
• Dimensions : 1.969 x 2.756 x 5.906 inch
• Weight : 1.036
• Panel Type : Siemens P1 Panelboards
• Standards : CSA Certified, HACR Rated, NOM Certified, UL Listed
• Certification : CSA Certified, HACR Rated, NOM Certified, UL Listed
