BDA261252 - Schneider Electric PowerPact B 125A 2 Pole 600Y/347VAC I-Line Circuit Breaker

Save $534.00
SKU: BDA261252-New
Condition: New
Price:
$935.00 $1,469.00
Stock:
Low inventory, please call for stock check

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

BDA261252 - Schneider Electric I-Line 600V 125A 2 pole circuit breaker 18kA@480V - Essential Electric Supply
BDA261252 - Schneider Electric/ Square D I-Line Style Plug-In 125 Amp 2 Pole Circuit Breaker - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
BDA261252 - Schneider Electric I-Line 600V 125A 2 pole circuit breaker 18kA@480V - Essential Electric Supply
BDA261252 - Schneider Electric/ Square D I-Line Style Plug-In 125 Amp 2 Pole Circuit Breaker - Essential Electric Supply

Description

BDA261252


BDA261252 is a Schneider Electric PowerPact B molded case circuit breaker designed for reliable thermal magnetic protection.This 2 pole, 125 amp circuit breaker operates at 600Y/347VAC with a breaking capacity of 14kA. It features an I-Line style plug-in mounting and includes long-time and instantaneous trip functions with thermal magnetic protection. Certified to UL, CSA, NOM, IEC, CCC standards and CE marked, it is suitable for single-phase applications.
    Key Specifications
    • Manufacturer: Schneider Electric
    • Series/Frame: PowerPact B
    • Amperage: 125A
    • Voltage: 600Y/347VAC
    • Poles: 2
    • Mounting Type: I-Line Style Plug-In
    • Interrupt Rating: 14kA @ 600Y/347VAC
    • Trip Unit: Thermal Magnetic with Long-Time and Instantaneous
    • Phase: Single Phase
    • Certifications: UL, CSA, NOM, IEC, CCC, CE
    • Connection: Load side mechanical lug terminals
    • Weight: Approximately 2.1 lb
    At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

    Specifications

    • Part Number: BDA261252
    • Manufacturer : Schneider Electric
    • Brand : Schneider Electric
    • Category : Circuit Breaker
    • Item Subcategory : Molded Case
    • Family : Powerpact
    • Type : BDA
    • Voltage : 600
    • Amperage : 125
    • Phase : 1
    • Poles : 2
    • AIC rating : 18kA@480V
    • Connection : I-Line
    • Functions : Long Time and Instantaneous Trip
    • Terminal Connection : I-Line, Lug
    • Frame Size : D
    • Temp Rating : -13–158 °F (-25–70 °C)
    • MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 2/0 AWG (Cu/Al)
    • Protection : Thermal Magnetic
    • Phase Connection : AC

    Product Data

    • UPC : 078590194203
    • GTIN : 00785901942030
    • Country of Origin : Mexico
    • Dimensions : 5.4 in (137 mm) x 2.1 in (54 mm) x 3.5 in (89 mm) (Height x Width x Depth)
    • Weight : 2.93
    • Standards : NEMA AB1, GB 14048.2, EN/IEC 60947-5-1, EN/IEC 60947-2, CSA C22.2 No 5, UL 489, NMX J-266
    • Certification : UL, IEC, CCC, EAC, CSA, NOM
    • Wire Size : AWG 14...AWG 2/0 aluminium/copper
