BDA260204 - Square D 20A 600V 2 Pole I-Line Thermal Magnetic Circuit Breaker BDA Frame

BDA260204

This circuit breaker features a BDA frame, 18kA interrupting rating at 480V, and long-time plus instantaneous trip functions. It supports load side mechanical lug terminal connections and is UL, IEC, CSA, CCC, EAC, and NOM certified. The breaker is designed for 1-phase systems with a temperature rating from -13 to 158 °F and accommodates wire gauges from AWG 14 to 2/0 aluminum or copper.

Key Specifications
• Amperage: 20A
• Voltage: 600V AC
• Poles: 2
• Mounting Type: I-Line Style Plug-In
• Interrupting Rating: 18kAIC @ 480V
• Frame Type: BDA
• Trip Unit: Thermal Magnetic with Long-Time and Instantaneous Functions
• Terminal Connection: Load Side Mechanical Lug
• Certifications: UL, IEC, CSA, CCC, EAC, NOM
• Phase: Single
• Operating Temperature: -13 to 158 °F (-25 to 70 °C)
• Wire Gauge: AWG 14 to 2/0 Aluminum/Copper

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: BDA260204
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : BDA
• Voltage : 600
• Amperage : 20
• Phase : 1
• Poles : 2
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : I-Line, Lug
• Frame Size : D
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 2/0 AWG (Cu/Al)
• Protection : Thermal Magnetic
• Phase Connection : BC



Product Data

• UPC : 060648115208
• GTIN : 03606481152084
• Country of Origin : Mexico
• Dimensions : 5.4 in (137 mm) x 2.1 in (54 mm) x 3.5 in (89 mm) (Height x Width x Depth)
• Weight : 3.091
• Standards : CSA C22.2 No 5, NEMA AB1, UL 489, GB 14048.2, EN/IEC 60947-2, EN/IEC 60947-5-1, NMX J-266
• Certification : UL, IEC, CCC, EAC, CSA, NOM
• Wire Size : AWG 14...AWG 2/0 aluminium/copper
