BDA260304 - Square D 30A 600V 2 Pole Thermal Magnetic Circuit Breaker I-Line Frame BDA

BDA260304

BDA260304 is a Square D 2 pole thermal magnetic circuit breaker rated for 30 amps and 600 volts AC with I-Line plug-in mounting.

This molded case circuit breaker features a BDA frame, 18kA interrupting rating at 480V, and long-time plus instantaneous trip functions. It supports load side mechanical lug connections and is UL, IEC, CCC, EAC, CSA, and NOM certified. Designed for reverse fed applications, it operates within temperature ranges from -25 to 70 °C and accommodates wire gauges from AWG 14 to 2/0 aluminum or copper.

Key Specifications
• Amperage: 30A
• Voltage: 600V AC
• Poles: 2
• Frame Type: BDA
• Mounting Type: I-Line Style Plug-In
• Interrupt Rating: 18kAIC @ 480V
• Trip Unit: Thermal Magnetic with Long-Time and Instantaneous Functions
• Connection Type: Load Side Mechanical Lug
• Certifications: UL, IEC, CCC, EAC, CSA, NOM
• Wire Gauge: AWG 14 to 2/0 Aluminum/Copper
• Operating Temperature: -25 to 70 °C (-13 to 158 °F)
• Dimensions (LxWxH): 3.5 x 2.13 x 5.39 inches

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BDA260304
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : BDA
• Voltage : 600
• Amperage : 30
• Phase : 1
• Poles : 2
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : I-Line, Lug
• Frame Size : D
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 2/0 AWG (Cu/Al)
• Protection : Thermal Magnetic
• Phase Connection : BC

Product Data

• UPC : 060648115212
• GTIN : 03606481152121
• Country of Origin : Mexico
• Dimensions : 5.4 in (137 mm) x 2.1 in (54 mm) x 3.5 in (89 mm) (Height x Width x Depth)
• Weight : 3.091
• Standards : EN/IEC 60947-5-1, EN/IEC 60947-2, CSA C22.2 No 5, UL 489, GB 14048.2, NMX J-266, NEMA AB1
• Certification : UL, IEC, CCC, EAC, CSA, NOM
• Wire Size : AWG 14...AWG 2/0 aluminium/copper
