Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
3VA4130-5ED34-0AA0
3VA4130-5ED34-0AA0 is a Siemens Sentron 3VA4 molded case circuit breaker designed for low voltage line protection in residential, commercial, and industrial applications. This 30-ampere, 3-pole unit features thermal-magnetic trip protection with long time and instantaneous trip functions, suitable for reverse-fed applications with non-interchangeable trip characteristics. The breaker utilizes load side lug terminals for secure connections and is rated for 600V AC operation with a 35 kA breaking capacity at 480V.
- Amperage: 30A
- Voltage: 600V AC
- Poles: 3
- Frame Type: 3VA4 (UL Frame 125)
- Breaking Capacity: 35 kA @ 480V (Class M)
- Trip Unit: TM210 with FTFM functions
- Mounting: Bolt-on
- Wire Size: 8 to 3/0 AWG
- Protection Type: Thermal-Magnetic
- Power Loss: 3W per pole at rated current
- Net Weight: 0.743 kg
Specifications
- Part Number: 3VA4130-5ED34-0AA0
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : 3VA
- Voltage : 600V AC
- Amperage : 30
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : LI
- Terminal Connection : Load Side Lug
- Frame Size : 125
- Temp Rating : -13¡F-158¡F (-25¡C-70¡C)
- Protection : Thermal Magnetic
- Trip Type : TM210
Product Data
- UPC : 804766943706
- GTIN : 00804766943706
- Country of Origin : Mexico
- Dimensions : 6.299 x 5.315 x 3.465 inch
- Weight : 1.638 lb
- Standards : UL Listed
- Certification : UL Listed
