Product Info
- Manufacturer:Merlin Gerin
- Sub-Category:Molded Case
Description
24474
24474 is a Merlin Gerin Multi9 C60N 3-pole thermal magnetic circuit breaker designed for reliable protection in commercial and industrial applications. This molded case circuit breaker features a 63A current rating, 480V AC voltage rating, and a C curve trip characteristic for optimal performance in typical load environments.Engineered for durability and safety, the 24474 breaker provides long-time and instantaneous trip functions with feed-thru connections and line & load side lug terminals. It is suitable for use in systems requiring 5kA interrupting capacity at 480V and is part of the widely recognized Multi9 series.
- Part Number: 24474
- Manufacturer: Merlin Gerin
- Series/Frame: Multi9 C60N
- Amperage: 63A
- Voltage: 480V AC
- Poles: 3
- Interrupt Rating: 5kA @ 480V
- Mounting Type: Feed-Thru
- Protection Type: Thermal Magnetic
- Phase: 3-Phase
- Connection: Line & Load Side Lug Terminals
- Trip Unit: C Curve (Type C)
Specifications
- Part Number: 24474
- Manufacturer : Merlin Gerin
- Brand : Merlin Gerin
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Multi9
- Type : 244
- Voltage : 480
- Amperage : 63
- Phase : 3
- Poles : 3
- AIC rating : 5kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- GTIN : 00785901892151
- Dimensions : Height 3.19 in (81 mm) x Depth 5.38 in (136.65 mm) x Width 5.64 in (143.26 mm)
- Weight : 6
