Product Info
- Manufacturer:Merlin Gerin
- Sub-Category:Molded Case
Description
24428
24428 is a Merlin Gerin Multi9 C60N series miniature circuit breaker designed for reliable protection in commercial and industrial applications. This 1-pole breaker is rated for 4 amps at 277 volts AC with a C-trip curve, suitable for general-purpose branch circuits. The 24428 features DIN rail mounting for easy installation and is part of the widely recognized Multi9 family. It offers a robust interrupt rating and is engineered for dependable performance in demanding environments.
- Part Number: 24428
- Manufacturer: Merlin Gerin
- Series: Multi9 C60N
- Poles: 1
- Rated Current: 4A
- Rated Voltage: 277VAC
- Interrupt Rating: 5kA @ 277V
- Mounting: DIN Rail
- Frame: C60N
- Trip Curve: C
- Type: Miniature Circuit Breaker (MCB)
- Certification: UL1077
Specifications
- Part Number: 24428
- Manufacturer : Merlin Gerin
- Brand : Merlin Gerin
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Multi9
- Type : 244
- Voltage : 277
- Amperage : 4
- Phase : 1
- Poles : 1
- AIC rating : 5kA@277V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- GTIN : 00785901346173
- Dimensions : Height 3.19 in (81 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
- Weight : 0.25
