Product Info
- Manufacturer:Merlin Gerin
- Sub-Category:Molded Case
Description
24426
24426 is a Merlin Gerin Multi9 C60 miniature circuit breaker designed for single-pole protection in industrial and commercial electrical systems.
This Type C curve circuit breaker provides reliable overcurrent and short-circuit protection with a standard interrupting capacity. The unit features long-time and instantaneous trip functions for enhanced protection. It is suitable for feed-thru mounting on DIN rails and supports multiple voltage ratings for flexible installation options.
- Manufacturer: Merlin Gerin
- Series: Multi9 C60
- Part Number: 24426
- Poles: 1
- Amperage: 2A
- Voltage: 277V AC (also rated 240V AC and 65V DC)
- Trip Curve: Type C
- Interrupt Rating: 5 kA @ 277V AC
- Mounting: Feed-Thru DIN Rail
- Trip Functions: Long-Time and Instantaneous (LI)
- Certification: UL1077
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: 24426
- Manufacturer : Merlin Gerin
- Brand : Merlin Gerin
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Multi9
- Type : 244
- Voltage : 277
- Amperage : 2
- Phase : 1
- Poles : 1
- AIC rating : 5kA@277V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- GTIN : 00785901346159
- Dimensions : Height 3.19 in (81 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
- Weight : 2
