XTCE150G00T - Cutler Hammer 150A 24VAC 3-Pole IEC Contactor Frame G Screw Terminals

XTCE150G00T

XTCE150G00T is a three-pole, 150A IEC contactor with a 24VAC coil, designed for reliable motor control applications. This full voltage non-reversing contactor features a 90mm frame and screw terminals for secure wiring. The XTCE150G00T is part of Eaton's XT IEC contactor series, offering robust performance for industrial environments. It is suitable for use in a wide range of motor control circuits and is compatible with both panel and DIN rail mounting. The contactor is built to meet IEC 60947 standards and provides efficient operation with low power consumption.

• 150A AC-3 rating
• 24VAC coil, 50/60Hz
• Three-pole configuration
• 90mm frame size
• Screw terminals
• Full voltage non-reversing
• Panel or DIN rail mounting
• Conforms to IEC 60947
• 0NO-0NC auxiliary contacts
• Operating temperature range: -25°C to +60°C
• UL 60335-2-40 certified
• A2L certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This includes a 24 VAC coil.

Specifications

• Part Number: XTCE150G00T
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : XT Series
• Type : XTCE150G
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• Horse Power : HP @ 3 Phase - 208V 40 hp HP @ 3 Phase - 240V 60 hp HP @ 3 Phase - 480V 125 hp
• Aux Contacts : No Auxiliary Contacts
• Coil Voltage Maximum : 24
• Full Load Amps : Full Load Amps-Inductive 150A Full Load Amps-Resistive 190A
• Coil Voltage Minimum : 24

Product Data

• UPC : 786685364858
• GTIN : 04015082395858
• Country of Origin : Romania
• Dimensions : 6.2992126 in x 6.69291339 in x 4.37007874 in (Length/Depth x Height x Width)
• Weight : 0.5070632 lb
• Certification : CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
