XTCE150G00A - Cutler Hammer 150A 3-Pole IEC Contactor 110-120V 50/60Hz Frame G Non-Reversing

XTCE150G00A

XTCE150G00A is a Cutler Hammer XT Series 150A, 3-pole IEC contactor designed for motor control applications with a coil voltage of 110-120 Vac at 50/60 Hz.This full voltage non-reversing contactor features a Frame G 90 mm size, screw terminals, and is rated for continuous current of 150A. It supports horsepower ratings up to 125 HP at 460V and complies with IEC 60947 standards. Certified UL Listed, CSA Certified, CE Marked, and RoHS compliant, it is suitable for reliable industrial motor control.

• Amperage Rating: 150A
• Voltage: 110-120 Vac, 50/60 Hz coil
• Poles: 3-pole
• Frame Size: G (90 mm)
• Contact Configuration: 0 NO, 0 NC
• Type: Full voltage non-reversing contactor
• Horsepower Rating: Up to 125 HP at 460V
• Terminals: Screw terminals
• Standards: IEC 60947
• Certifications: UL Listed, CSA Certified, CE Marked, RoHS Compliant
• Operation: Non-reversing

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This IEC Non-Reversing Contactor includes a 110 VAC coil.

Specifications

• Part Number: XTCE150G00A
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : XT Series
• Type : XTCE150G
• Voltage : 600
• Amperage : 150
• Poles : 3
• Horse Power : HP @ 3 Phase - 208V 40 hp HP @ 3 Phase - 240V 60 hp HP @ 3 Phase - 480V 125 hp
• Configuration : Non-Reversing
• Aux Contacts : 0 NO + 0 NC
• Coil Voltage Maximum : 120
• Full Load Amps : Full Load Amps-Inductive 150A Full Load Amps-Resistive 190A
• Coil Voltage Minimum : 100
• Frequency : 50 Hz

Product Data

• UPC : 01508239587
• GTIN : 04015082395872
• Country of Origin : Romania
• Dimensions : 6.2992126 in x 6.69291339 in x 4.37007874 in (Length/Depth x Height x Width)
• Weight : 0.5070632 lb
• Certification : CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
