Product Description & Specifications
Confirm the complete catalog number and application requirements before ordering. The specifications below reflect the product information available for this listing.
- Manufacturer
- Connecticut Electric
- Sub-Category
- Molded Case
- Series
- Pushmatic
- Frame
- UBIP
- Rated current
- 40
- Voltage
- 120/240V
- Poles
- 2
- Phases
- 1
- Interrupting rating
- 10kA@240V
- Trip functions
- Long Time and Instantaneous Trip
- Protection
- Thermal Magnetic
- Connection
- Plug-In
- Country of origin
- China
- Temp Rating
- -13°F to 158°F (-25°C to 70°C)
Show all specifications (5 more)
- UPC
- 009492503106
- GTIN
- 00094925031065
- Dimensions
- 1.5 in x 3.81 in x 3.81 in
- Weight
- 2 lb
- Certification
- ETL Listed, UL Listed
Product description & additional details
UBIP240
UBIP240 is a Connecticut Electric 2-pole circuit breaker rated for 40 amps and 120/240 volts designed for plug-in mounting.This circuit breaker features a 10,000 A interrupt rating and is classified for use in Pushmatic and Bulldog load centers. It is ETL listed and suitable for single-phase applications, providing reliable protection and safe power distribution.
- Amperage: 40 A
- Voltage: 120/240 VAC
- Poles: 2
- Mounting Type: Plug-In
- Interrupt Rating: 10,000 AIC
- Series/Frame: Type UBIP
- Trip Unit: Thermal Magnetic
- Certifications: ETL Listed
- Compatible with Pushmatic and Bulldog load centers
- Dimensions: 3.95 in L x 1.5 in W x 2.6 in H
Specifications
- Part Number: UBIP240
- Manufacturer : Connecticut Electric
- Brand : Connecticut Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Pushmatic
- Type : UBIP
- Voltage : 120/240
- Amperage : 40
- Phase : 1
- Poles : 2
- AIC rating : 10kA@240V
- Connection : Plug-In
- Functions : Long Time and Instantaneous Trip
- Temp Rating : -13°F to 158°F (-25°C to 70°C)
- Protection : Thermal Magnetic
Product Data
- UPC : 009492503106
- GTIN : 00094925031065
- Country of Origin : China
- Dimensions : 1.5 in x 3.81 in x 3.81 in
- Weight : 2 lb
- Certification : ETL Listed, UL Listed
