2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
THJK436350LL
THJK436350LL is a 3 pole molded case circuit breaker from General Electric designed for industrial power distribution applications. This thermal magnetic breaker features a 350 amp current rating and 600 volt maximum AC voltage rating, with an interchangeable trip unit for flexible protection configuration. The unit includes both line and load side lug terminals for secure connections and is part of the General Electric J600 line of circuit protection products. Key Specifications
- Part Number: THJK436350LL
- Manufacturer: General Electric
- Type: THJK Molded Case Circuit Breaker
- Amperage Rating: 350A
- Voltage Rating: 600V AC, 500V DC
- Poles: 3
- Trip Unit: Interchangeable Thermal Magnetic
- Terminal Connection: Line and Load Side Lugs
- Interrupt Rating: 35kA at 480V
- Weight: 15.33 lbs
Specifications
- Part Number: THJK436350LL
- Manufacturer : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : J600 Line
- Type : THJK
- Voltage : 600
- Amperage : 350
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 783164234107
- GTIN : 00783164234107
- Weight : 18
