Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
THJK436250WL
THJK436250WL is a 250 Amp, 3 Pole thermal magnetic molded case circuit breaker from General Electric, designed for industrial and commercial electrical protection.This circuit breaker features a J600 frame type with a voltage rating up to 600 VAC and a high interrupting capacity, including 65 kAIC at 120/240V and 35 kAIC at 480V. It includes line and load side lug terminals for secure connections and an interchangeable trip unit with fixed long time and adjustable instantaneous trip functions. The breaker is UL and CSA certified, suitable for demanding environments requiring reliable circuit protection.
- Amperage: 250 A
- Poles: 3
- Voltage: 600 VAC max
- Frame Type: J600 (THJK4 series)
- Interrupting Rating: 65 kAIC at 120/240V, 35 kAIC at 480V, 25 kAIC at 600V
- Trip Unit: Thermal Magnetic, interchangeable
- Mounting: Feed-Thru with line and load side lug terminals
- Trip Functions: Fixed Long Time, Adjustable Instantaneous
- Certifications: UL File #E11592, CSA File #LR40350
- Suitable for commercial and industrial applications
Specifications
- Part Number: THJK436250WL
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : J600 Line
- Type : THJK
- Voltage : 600
- Amperage : 250
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous Trip
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- GTIN : 00783164046915
- Weight : 18
