Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
THJK436250LL
THJK436250LL is a 3 pole, 600 volt, 250 amp rated molded case circuit breaker from General Electric's J600 Line family. This thermal magnetic circuit breaker features bolt-on mounting with line and load side lug terminals and an interchangeable trip unit for reliable power distribution and protection. Key Specifications
- Part Number: THJK436250LL
- Manufacturer: General Electric
- Type: Molded Case Circuit Breaker
- Frame: THJK (J600 Line)
- Poles: 3
- Amperage: 250 Amps
- Voltage: 600 VAC, 500 VDC
- Interrupting Rating: 35 kA at 480V
- Protection: Thermal Magnetic
- Mounting: Bolt-On
- Terminals: Line and Load Side Lugs
- Trip Unit: Interchangeable
Specifications
- Part Number: THJK436250LL
- Manufacturer : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : J600 Line
- Type : THJK
- Voltage : 600
- Amperage : 250
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 783164234060
- GTIN : 00783164234060
- Weight : 18
