Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
TED134050WL
TED134050WL is a General Electric 3-pole, 50 amp, 480 volt molded case circuit breaker designed for reliable power distribution protection.This circuit breaker features a thermal magnetic trip unit with a fixed long-time and instantaneous trip, suitable for 3-phase systems. It has an E150 frame type and a high interrupting rating of 18kA at 480VAC, ensuring robust fault current interruption. The breaker supports feed-through mounting and includes line and load side lug terminals. It is UL and CSA certified, HACR rated, and suitable for reverse feed applications.
- Key Specifications
- Amperage: 50 A
- Voltage Rating: 480 VAC
- Poles: 3
- Frame Type: E150
- Interrupting Rating: 18kA at 480 VAC
- Trip Unit: Thermal Magnetic, Fixed Long-Time and Instantaneous
- Mounting Type: Feed-Through
- Certifications: UL Listed (E11592), CSA Certified (LR57114), HACR Rated
- Suitable for Reverse Feed: Yes
- Lug Type: Line and Load Side Terminals
Specifications
- Part Number: TED134050WL
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : E150 Line
- Type : TED
- Voltage : 480
- Amperage : 50
- Phase : 3
- Poles : 3
- AIC rating : 18kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 078316406308
- GTIN : 40783164063088
- Weight : 3
- Certification : UL
