QR23B100L - Siemens 100A 240V 3 Pole Molded Case Circuit Breaker Bolt-On 10kA Interrupt Rating

QR23B100L

QR23B100L is a Siemens 3 pole molded case circuit breaker rated for 100 amps and 240 volts with a bolt-on mounting type and 10kA interrupt rating.This Siemens QR23B100L circuit breaker features a thermal magnetic trip unit designed for reliable protection in commercial and industrial applications. It is part of the QR series with a 3-pole configuration suitable for 240V systems. The breaker has a bolt-on connection type and a 10,000 amp interrupting capacity at 240 volts. It is UL489, CSA, and NOM certified, ensuring compliance with North American safety standards.

• Amperage: 100 Amps
• Voltage: 240 Volts
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 10kA @ 240V
• Series/Frame: QR Series (QR2 type)
• Trip Unit: Thermal Magnetic (LI - Long-Time and Instantaneous)
• Certifications: UL489, CSA, NOM
• Application: Load centers, panelboards, powerpanels, switchboards
• Push-to-trip button for testing
• Non-interchangeable trip unit

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QR23B100L
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 240
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 10kA@240V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Protection : Thermal Magnetic

Product Data

• UPC : 804766136696
• GTIN : 00804766136696
• Country of Origin : Mexico
• Dimensions : 7.087 x 4.331 x 3.937 inch
• Weight : 4.519
• Wire Size : 6 AWG to 1/0 AWG (Aluminum/Copper)
