QOU2301021 - Square D 30A 2 Pole 120/240V Miniature Circuit Breaker 10kA Shunt Trip

QOU2301021

QOU2301021 is a Square D 30 Amp, 2 Pole miniature circuit breaker designed for 120/240 Volt applications with a 10kA interrupt rating and shunt trip feature.QOU2301021 provides reliable circuit protection with thermal magnetic trip technology, suitable for panel mounting. It supports 50/60 Hz frequency and is built to meet industry certifications for safety and performance.

• Amperage: 30 Amps
• Voltage: 120/240 VAC, 48 VDC
• Number of Poles: 2
• Interrupt Rating: 10 kA at 120/240 V AC
• Trip Unit: Thermal Magnetic with Shunt Trip
• Mounting Type: Panel Mount
• Series/Frame: QOU Standard
• Frequency: 50/60 Hz
• Terminal Connection: Box Lugs
• Certifications: UL Listed, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QOU2301021
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 240
• Amperage : 30
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901517948
• GTIN : 00785901517948
• Country of Origin : Mexico
• Dimensions : 4.05 in (102.87 mm) x 2.25 in (57.15 mm) x 2.95 in (74.93 mm) (Height x Width x Depth)
• Weight : 1.16
• Certification : IEC - UL listed - CSA
• Wire Size : AWG 14...AWG 2 aluminium/copper
